Somewhere beneath Kansas, a well drilled in the 1980s for natural gas kept returning an unexpected reading: hydrogen, in concentrations high enough to notice but not high enough for anyone to care about at the time. Decades later, that well is one of hundreds of data points feeding a new map that could reshape how the United States thinks about clean fuel. In June 2026, the U.S. Geological Survey’s first continent-wide prospectivity map for naturally occurring hydrogen is drawing attention from energy startups, major oil companies, and federal regulators alike.
Published as Professional Paper 1900, the map scores regions across the lower 48 states by their likelihood of containing hydrogen in source rocks, reservoirs, and sealing formations. It was built from 21 geologic and geophysical data layers and represents the first time any national survey has offered a public, systematic ranking of where geologic hydrogen might accumulate. The map does not predict how much hydrogen is down there or whether extracting it would be profitable. What it does is tell drillers where the geology is most favorable, and for a resource class that barely had a search grid a few years ago, that alone is a significant shift.
What the map actually shows
The USGS announced the map as the first publicly available prospectivity assessment for geologic hydrogen accumulations in the contiguous United States. Each cell on the map receives a relative score, from low to high, based on how many favorable geologic conditions overlap in that zone. A high score means the area has the right combination of hydrogen-generating rocks, structures that could trap migrating gas, and cap rocks that could seal it in place.
Those scores draw on data layers that include well-gas analyses, geothermal gradient measurements, sedimentary basin boundaries, and aeromagnetic surveys. Among the most concrete inputs: actual hydrogen concentrations measured in drill-well gas samples. The USGS flags any occurrence above 0.5 mol% hydrogen as a known detection, and those detections are scattered across multiple basins, from the Midcontinent Rift system to parts of Appalachia.
Two data layers do particularly heavy lifting. Aeromagnetic data, processed with a 500-km high-pass filter, help identify mid-crustal magnetic anomalies that can signal iron-rich rocks capable of generating hydrogen through water-rock reactions, a process geologists call serpentinization. Sedimentary basin polygons, digitized from the Frezon and Finn (1988) catalog in the USGS basin archive, define the boundaries of geologic containers where hydrogen could migrate and pool. The overlap of strong magnetic signatures with basin geometry and confirmed gas detections is what gives certain zones their high scores.
The agency also launched an interactive tool it calls the Hydrogen Map Explorer, where users can toggle individual input layers, view the integrated prospectivity result, and examine the separate source, reservoir, and seal components behind each score. The transparency is deliberate: anyone can check which layers drive a high score in a particular county and whether known hydrogen detections line up with the model’s predictions.
Why this matters now
Geologic hydrogen, sometimes called “gold hydrogen” or “white hydrogen,” forms naturally underground when water reacts with iron-rich minerals at elevated temperatures and pressures. Unlike green hydrogen (produced by splitting water with renewable electricity) or gray hydrogen (made from natural gas with significant carbon emissions), geologic hydrogen requires no industrial energy input. It simply accumulates, provided the right rocks and conditions exist.
The concept is not purely theoretical. In the village of Bourakébougou, Mali, a well drilled in the 1980s has been producing geologic hydrogen and generating electricity for local use for years, making it the world’s only known producing geologic hydrogen site. In the United States, the startup Natural Hydrogen Energy has been exploring in Nebraska, and Koloma, backed by Bill Gates’s Breakthrough Energy Ventures, has raised hundreds of millions of dollars to hunt for the resource domestically. The Department of Energy has also funded research into geologic hydrogen’s potential, signaling federal interest beyond the USGS mapping effort.
What was missing until now was a national-scale framework for deciding where to look. Individual researchers and companies had identified promising spots, but there was no standardized, publicly available assessment that ranked the entire lower 48. The USGS map fills that gap. In a 2023 study that preceded this map, the agency estimated that the Earth could hold up to roughly 5.5 trillion metric tons of geologic hydrogen in the subsurface, though only a small fraction of that would be accessible or economically recoverable. The new map begins the work of figuring out where that fraction might be found in the United States.
What remains uncertain
The map narrows the search, but it cannot answer the questions that matter most to investors and regulators: How much hydrogen is actually down there? Can it be extracted at a competitive cost? And what happens to the reservoir once you start pumping?
Professional Paper 1900 contains no quantitative estimate of recoverable hydrogen from any identified zone. Prospectivity scores reflect geologic favorability, not proven reserves, and the distance between those two concepts is vast. A region can score high because it has the right rock types, thermal conditions, and trapping structures while still holding too little hydrogen, or hydrogen buried too deep, to justify a commercial well.
Permitting is another open question. Oil-and-gas regulatory frameworks were designed for hydrocarbons, and most states have not yet defined how they will classify or permit wells drilled specifically for naturally occurring hydrogen. Mineral rights, lease terms, and environmental review requirements all remain unsettled, which could slow early exploration regardless of what the geology looks like.
The relationship between the map’s magnetic anomaly layer and actual hydrogen concentrations at depth has not been validated at scale. The 500-km high-pass filter highlights broad crustal features, but whether those features correspond to economically meaningful hydrogen pools is an empirical question that only drilling can answer. Helium co-occurrence data offer a partial check, since helium and hydrogen sometimes share migration pathways, but the correlation is inconsistent across different geologic settings.
The USGS conducted a formal peer review of the work, but the agency has not published the raw reviewer comments or detailed how the 21 input layers were weighted relative to one another. Outside researchers can evaluate the final methodology but cannot trace how competing interpretations were resolved during the review process.
Where the drill bit meets the model
For the companies already spending money on geologic hydrogen exploration, the map offers a way to prioritize. Zones where high prospectivity scores overlap with confirmed well-gas detections and strong magnetic signatures represent the lowest-risk targets for early test wells. Zones that score high on modeled layers alone, without corroborating gas measurements, warrant more caution and likely more preliminary fieldwork before committing to a drill program.
For state regulators, the map is an early warning system. High-scoring zones in their jurisdictions will attract permit applications, and the regulatory infrastructure to handle those applications largely does not exist yet. States that move early to define leasing rules, environmental standards, and data-sharing requirements for hydrogen exploration will have an advantage over those that wait for the first permit request to force the issue.
For the broader energy picture, the map converts geologic hydrogen from a curiosity into a testable proposition. Each high-scoring region is effectively a hypothesis: the geology here should favor hydrogen accumulation. Drillers will either confirm that hypothesis or generate new data that sharpens the next version of the model. The USGS has said it plans to update the map as new well data and research become available, meaning the current release is a starting point, not a final product.
None of this guarantees that geologic hydrogen will become a major energy source. The history of resource exploration is full of maps that pointed to real deposits that turned out to be uneconomic, and hydrogen presents unique challenges: it is the smallest molecule, prone to leaking through rock and steel alike, and separating it from co-produced gases adds cost. But the USGS has now given the search a structure it did not have before, and the companies, regulators, and researchers who act on it will determine whether the fuel that makes itself underground can also power what we build on the surface.
