The Milky Way’s magnetic field, the invisible scaffold that steers cosmic rays and shapes the gas between stars, has been hiding a secret. A team of radio astronomers has discovered that the field reverses direction along a steeply tilted plane cutting through our local stretch of the galaxy, a structural twist that no existing model predicted and that had gone undetected until a new broadband survey finally had the resolution to see it.
The finding, published in The Astrophysical Journal, emerged from the GMIMS-DRAGONS survey, which mapped polarized radio emission across the entire northern sky using the Dominion Radio Astrophysical Observatory’s 15-meter telescope in British Columbia. By scanning continuously from 350 to 1,030 MHz, the survey could separate overlapping magnetic structures that narrower-band observations had always blurred together. What the team found was a boundary, modeled as a plane whose orientation points toward Galactic coordinates of roughly 168.5 degrees longitude and minus 60 degrees latitude, where the magnetic field on one side runs in the opposite direction from the field on the other.
The clue that gave it away
The giveaway was a lopsided pattern in something called Faraday depth, a measure of how much polarized radio light rotates as it travels through magnetized gas. When the astronomers mapped Faraday depth across the sky, they found that the signal’s sign, essentially the direction the magnetic field points along a given line of sight, flipped once in the southern Galactic hemisphere but twice in the north.
A uniform magnetic field would never produce that kind of asymmetry. Only a field that reverses direction along a tilted plane can account for the mismatch, because the plane intersects different numbers of sight-lines in each hemisphere. The team tested this interpretation against their data and found that the tilted-plane model reproduced the observed sign changes far better than any simple, smooth-field alternative.
How the survey pulled it off
Earlier radio surveys lacked either the frequency range or the sensitivity to catch this reversal. DRAGONS changed both. Equipped with a prototype SKA band-1 feed built at Sweden’s Onsala Space Observatory, the DRAO telescope achieved a Faraday-depth resolution of about 6 rad m-2 and a median sensitivity near 11 millikelvin, according to the survey’s technical paper in the Astrophysical Journal Supplement Series. Angular resolution ranged from roughly 1.3 to 3.6 degrees depending on frequency, and the survey covered declinations from minus 20 degrees to 90 degrees.
The underlying technique dates to a 1966 paper by M.A. Burn, which laid out the mathematics of Faraday dispersion, the framework radio astronomers still use to disentangle magnetic-field signals stacked along a single line of sight. DRAGONS applied that decades-old formalism to a far wider frequency range than Burn could have imagined, and the payoff was immediate: structures that had been invisible in older, narrower surveys snapped into focus.
What the discovery could change
If the reversal holds up, it carries real consequences for how scientists model cosmic-ray transport through the galaxy. Cosmic rays, high-energy particles that constantly bombard Earth, follow the Milky Way’s magnetic field lines like cars on a highway. A previously unknown reversal means the highway has an unexpected U-turn, and models that assumed a smooth road through the solar neighborhood will need to be updated.
The reversal also raises a tantalizing question about the Local Bubble, the roughly 300-light-year-wide cavity surrounding the Sun that was hollowed out by ancient supernovae. The magnetic shell of the Local Bubble could, in principle, produce a detectable shift in Faraday depth. But neither the discovery paper nor the survey paper draws a direct connection between the reversal plane and three-dimensional maps of the Local Bubble’s boundaries. That comparison remains a hypothesis for future work, not a confirmed link.
Another open question is scale. The DRAGONS data are most sensitive to relatively nearby magnetized gas, and the modeling does not yet pin down whether the reversal plane is a purely local phenomenon, perhaps shaped by the specific history of supernova explosions and stellar winds near the Sun, or part of a larger pattern woven into the Milky Way’s spiral-arm structure. A local reversal would be interesting. A kiloparsec-scale reversal would force a deeper rethinking of how the galaxy’s magnetic dynamo operates.
The caveats worth knowing
The result is compelling, but it is not yet bulletproof. About 25 percent of the DRAGONS data were lost to radio-frequency interference, and no public statement from the team quantifies how that loss, or the choices made during calibration, might shift the precise orientation of the reversal plane. The coordinates represent a best-fit model, and the error bars on that geometry have not been tested by an independent group.
The raw data are publicly available through a CANFAR data repository, so outside researchers can download the survey’s data cubes and attempt to reproduce the pattern. As of June 2026, no independent reanalysis has been published confirming or challenging the result. Until one appears, the community is relying on a single pipeline and a single set of modeling assumptions.
There is also a coverage gap. DRAGONS only reaches declinations down to minus 20 degrees, which means the single sign change reported in the southern Galactic hemisphere rests on incomplete sky data. A full southern-sky counterpart survey would be needed to confirm whether that pattern holds across the entire southern hemisphere or whether additional, unresolved structures lurk below the survey’s horizon.
What comes next for Galactic magnetism
The practical next step is straightforward: independent groups need to reprocess the publicly released DRAGONS cubes using different analysis codes and calibration assumptions. If the sign-alternation pattern survives those tests, the case for a genuine large-scale reversal in the local Galactic magnetic field will strengthen considerably. If modest changes in data flagging or foreground modeling erase or relocate the apparent plane, the original interpretation will need revisiting.
Either outcome would be valuable. The DRAGONS survey has already delivered the most detailed broadband Faraday-depth map of the northern sky ever produced, a benchmark dataset that will anchor magnetic-field studies for years. The proposed reversal plane may turn out to be the first glimpse of a more intricate magnetic architecture threaded through the solar neighborhood, one that has been shaping cosmic-ray paths and interstellar gas flows all along, just beyond the reach of older instruments.
