Researchers at the University of New South Wales have redesigned the internal plumbing of hydrogen fuel cells to tackle one of the technology’s oldest problems: water buildup that chokes performance. By adding microscopic lateral bypass channels and micro-ribs to a standard serpentine flow field, the team reports performance gains of up to 75% compared with conventional designs when running on hydrogen and air at ambient pressure. The work, published in a peer-reviewed Elsevier journal, offers a concrete engineering fix for a barrier that has kept polymer electrolyte membrane fuel cells from competing with batteries in cars and stationary power systems.
What is verified so far
The core technical claim rests on a single, clearly defined modification. The UNSW team introduced 100-micrometer lateral bypasses and 100-micrometer micro-ribs into a serpentine flow field, the most common channel layout used to distribute reactant gases across a fuel cell’s active area. That geometry change produced performance up to roughly 75% higher than a baseline serpentine design under hydrogen-air operation at ambient pressure. The paper attributes the gain to suppression of concentration losses caused by liquid water accumulating in the channels and under the ribs that separate them.
The research team includes Dr Quentin Meyer and Prof Chuan Zhao, both at UNSW, alongside co-authors Peyman Mostaghimi and Ying Da Wang. A UNSW press statement confirms the same 75% top-line figure and describes the design as incorporating “microscopic channels” and “lateral bypasses.” Dr Meyer is quoted as framing the advance as a step toward unlocking hydrogen fuel cells for clean energy applications, particularly where rapid load changes and high current densities have historically exposed water-management weaknesses.
Why does water matter so much inside a fuel cell? In a PEM cell, hydrogen and oxygen react across a thin membrane to produce electricity and water. That product water must exit the cell quickly. If it pools in the flow channels or beneath the ribs that press against the gas diffusion layer, it blocks fresh oxygen from reaching the catalyst. The result is a steep voltage drop at high current densities, exactly the operating regime needed for real-world loads like highway driving or peak grid demand. Independent review literature confirms that under-rib flooding is a recognized failure mode across serpentine, parallel, and interdigitated flow-field architectures, and that it can dominate performance losses once ohmic resistance has been minimized.
Separate research into baffle-based flow-field geometries has shown that small structural features inside channels can meaningfully improve oxygen and water-vapor distribution. A recent study on aerodynamic baffle structures reported measurable performance gains by reshaping internal channel geometry to promote mixing and to disrupt stagnant liquid films. That broader body of work supports the premise that micro-scale and meso-scale geometry changes affect mass transport and water management in ways that translate directly to higher power output, lending external plausibility to the UNSW approach even though the specific lateral bypass pattern is new.
The UNSW team’s methodology also draws credibility from the use of operando neutron imaging, a technique that can visualize liquid water inside an operating fuel cell without disassembling it. Neutron beams interact strongly with hydrogen atoms, making them far more sensitive to water than X-rays are. Research published in Physical Chemistry Chemical Physics has demonstrated that neutron imaging applied to PEM fuel cells can reveal water and ice distribution during realistic automotive operating modes, including cold starts and load cycles. A separate study in an open-access journal explains how combined operando tomography resolves water distribution against metal hardware components, providing spatial detail that electrochemical measurements alone cannot capture.
In the UNSW work, neutron imaging is used to correlate the presence or absence of liquid water with voltage output under different current loads. That pairing of visual and electrochemical evidence is important: it reduces the risk that apparent performance improvements are artifacts of measurement or test setup. While the imaging data available in the public reporting are limited in resolution and duration, they align qualitatively with the claim that lateral bypasses help clear water from regions that would otherwise flood.
What remains uncertain
The 75% performance figure, while striking, comes with important caveats that the available sources do not fully resolve. The measurement was taken under hydrogen–air conditions at ambient pressure, a useful laboratory benchmark but not a direct proxy for the pressurized, humidified, and thermally managed environment inside a commercial fuel cell stack. Whether the lateral bypass design retains its advantage at two or three atmospheres of back-pressure, or at the elevated temperatures typical of automotive systems, is not addressed in the published data available for review. It is possible that improved water removal at ambient pressure could translate differently once gas densities, humidification strategies, and compressor power penalties are factored in.
Durability is another open question. Flow-field modifications that improve short-term water removal can sometimes accelerate membrane drying on the inlet side, creating a different degradation pathway. Localized dry-out can increase mechanical stress on the membrane, promote pinhole formation, and change the distribution of catalyst utilization over time. No long-term cycling data or accelerated stress test results from the UNSW team have been disclosed in the sources examined. The neutron imaging studies cited for methodological context were conducted by independent groups and do not validate the specific lateral bypass geometry over thousands of hours of operation or under repeated freeze-thaw cycles.
Manufacturing feasibility also lacks detail. Producing 100-micrometer features in metallic bipolar plates typically requires precision stamping, laser machining, or chemical etching, all of which add cost relative to standard stamped plates. Neither the journal paper’s abstract nor the broader UNSW institutional information provide estimates of per-unit cost increases or describe a scalable fabrication route suitable for high-volume automotive manufacturing. For an industry where bipolar plates already account for a significant share of stack cost and are manufactured by the millions, that omission matters. Even a modest percentage cost increase per plate could offset efficiency gains unless it is balanced by higher power density that allows fewer cells per stack.
Finally, no head-to-head comparison with interdigitated flow fields, which force gas through the diffusion layer and are often cited as the strongest alternative for water removal, appears in the available reporting. The review literature catalogues multiple competing architectures, including parallel, multi-pass serpentine, and various hybrid layouts, but the UNSW study benchmarks its design only against a conventional serpentine baseline. That choice makes the 75% figure harder to contextualize against the full field of design options. Without such comparisons, it remains unclear whether lateral bypasses represent a step-change over the best existing industrial designs or a targeted improvement over a known but conservative geometry.
How to read the evidence
The strongest piece of evidence here is the peer-reviewed paper itself, published in Applied Catalysis B: Environment and Energy. It contains the specific geometry dimensions, the performance comparison, and the claim about suppressed concentration losses. Readers evaluating the 75% figure should note that it represents a best-case gain (“up to”), not an average across all operating conditions. That phrasing is standard in electrochemistry literature but can be misread as a typical improvement rather than a peak value under optimized settings.
When weighing the significance of the UNSW results, it helps to separate three layers of confidence. At the first layer, the basic physics—that micro-scale features in the flow field can influence water removal and thus power output—is well supported by prior work on under-rib flooding, baffle geometries, and neutron visualization techniques. At the second layer, the specific experimental finding that lateral bypasses improve performance under the reported test conditions is backed by peer-reviewed data and by imaging that shows reduced liquid accumulation in critical regions. At the third layer, the extrapolation from laboratory-scale cells at ambient pressure to commercial stacks under real duty cycles remains speculative.
For now, the lateral bypass design is best understood as a promising engineering refinement with strong laboratory support and meaningful but bounded implications. It offers a tangible route to addressing a widely recognized bottleneck in PEM fuel cells, yet its real-world impact will depend on durability, manufacturability, and competitiveness against alternative flow-field concepts. Further publications with long-term testing, cost analysis, and broader benchmarking will be needed before it can be treated as a proven pathway to commercial hydrogen fuel cell breakthroughs.
