Scientists at Oak Ridge National Laboratory have found that applying an electric field to a specialized ceramic can nearly triple the rate at which heat moves through the material in one direction. The finding, published in PRX Energy, represents the largest such thermal conductivity jump ever recorded in a solid using electric-field control, and it could reshape how engineers manage waste heat in electronics, batteries, and energy systems.
How Phonons Carry the Heat
Heat travels through solid materials via phonons, which are tiny vibrations of atoms in a crystal lattice. The efficiency of that transfer depends on how long each phonon survives before scattering off defects or other phonons. In most solids, these lifetimes are fixed by the material’s structure, leaving engineers with few options to adjust heat flow after a device is built.
The new study, led by ORNL senior researcher Michael Manley, showed that an external electric field can change those rules in real time. When applied to a class of ceramics called relaxor-based ferroelectrics, the field reorganizes nanoscale polar regions inside the material, aligning atomic vibrations so that energy flows more efficiently along the field direction. Phonons with atoms moving along that direction last significantly longer than those vibrating perpendicular to it, creating a strong directional preference for heat conduction.
A Nearly Threefold Jump Over Prior Results
The scale of the effect is what sets this work apart. Earlier experiments on bulk ferroelectrics managed to improve thermal conductivity by only about 5 to 10 percent. Separate computational work on the perovskite PbTiO3 demonstrated modulation of up to roughly 50 percent at room temperature, as shown in first-principles simulations, a notable step but still far short of what would be needed for a practical thermal switch.
Manley’s team, working in collaboration with The Ohio State University and Ames Laboratory, achieved heat conduction almost three times more efficient along the field direction than perpendicular to it. That result, confirmed through neutron-scattering and transport measurements at ORNL’s Spallation Neutron Source, represents a qualitative leap. Instead of fine-tuning a material’s thermal properties by a few percentage points, the researchers produced a directional on–off contrast large enough to function as a genuine solid-state heat valve.
Why Relaxor Ferroelectrics Behave Differently
Standard ferroelectrics have a single, well-defined polar state. Relaxor ferroelectrics are messier. Their crystal lattices contain clusters of polar order at the nanometer scale, and those clusters point in many directions at once. That disorder is exactly what makes them responsive to an external field. When voltage is applied, the scattered polar nano-regions snap into alignment, and the phonon spectrum shifts accordingly.
Foundational research using high-energy X-ray diffuse scattering under applied electric fields had already shown that fields restructure nanoscale polar order in relaxors. The ORNL team built on that insight by measuring the thermal consequences directly. In the relaxor ferroelectric PMN-33PT, electric-field-dependent thermal conductivity tracked closely with changes in the phonon spectrum, confirming that the mechanism is phonon lifetime extension rather than some secondary effect.
This distinction matters because it means the thermal switch is reversible. Remove the field and the polar nano-regions scramble again, phonon lifetimes drop, and heat conduction falls back. The method provides a way to turn heat flow on and off with a low voltage, much like a light switch controls electricity, but without moving parts or mechanical actuators.
A Long-Standing Gap in Thermal Control
Engineers have had precise electronic switches for more than a century. Thermal equivalents have lagged far behind. Devices that allow heat flow to be controlled with the same precision as current in a transistor remain rare, in part because phonons are difficult to manipulate. They carry no charge, interact strongly with imperfections, and propagate over a broad range of wavelengths and directions.
Previous attempts to bridge this gap explored several angles. Some researchers tuned phonon-related modes in ferroelectrics to control near-field radiative heat transfer, as demonstrated in work cataloged by the U.S. Department of Energy on radiative phonon coupling. That approach exploits evanescent electromagnetic fields across nanometer-scale gaps, rather than conduction through a bulk solid. Others have proposed thermal diodes and rectifiers based on asymmetric lattices, interface engineering, or phase transitions, including theoretical designs for phononic logic elements that would process information using heat instead of charge.
Each of these strategies offered incremental progress, but most fell short on at least one practical front: the achievable contrast between high and low thermal states, the operating temperature range, the speed and reversibility of switching, or the ease of integrating the materials into real devices. In many cases, the predicted effects were large in simulations but difficult to reproduce in bulk samples or at room temperature.
From Incremental Tweaks to a True Thermal Valve
The ORNL result changes the calculus by demonstrating a large, field-controlled contrast in a robust ceramic. In their relaxor-based ferroelectric, the team saw nearly a threefold difference in thermal conductivity along the field direction compared with the perpendicular direction. Because the effect arises from reorganizing existing polar nano-regions rather than creating new defects or triggering a permanent phase change, the switching is intrinsically reversible.
Crucially, the electric fields involved are modest by the standards of ferroelectric devices, and the response occurs in the bulk of the material rather than being confined to an interface or a nanoscale gap. That opens the door to macroscopic components, thermal “wires” whose conductance can be dialed up or down on demand, or anisotropic heat spreaders that steer waste heat toward or away from sensitive regions of a circuit.
The work also dovetails with broader efforts to engineer thermal transport in complex oxides. Studies of lattice dynamics in perovskites have underscored how strongly phonon behavior depends on subtle structural distortions and polar instabilities. Relaxor ferroelectrics sit at an especially rich point in this landscape, with their fluctuating polar regions and strong coupling between electrical and vibrational degrees of freedom providing multiple levers for control.
Potential Applications and Remaining Challenges
If the effect can be scaled and engineered into manufacturable components, field-tunable thermal conductivity could impact several sectors. In power electronics and data centers, dynamically controlled heat conduits might route heat away from overloaded chips and toward dedicated sinks only when needed, improving reliability without overdesigning passive cooling systems. In batteries, switchable thermal pathways could help equalize cell temperatures during fast charging while limiting heat flow during storage.
Thermal management is also a key bottleneck for high-density 3D integration, where traditional heat sinks struggle to reach buried layers. A network of controllable thermal vias made from relaxor ferroelectrics could, in principle, provide a programmable heat-extraction path that adapts as workloads shift. Beyond cooling, tunable thermal transport might enable new classes of thermal logic and memory devices that exploit temperature gradients as an information carrier, complementing earlier conceptual work on heat-based computation.
Significant challenges remain before such visions can be realized. Relaxor ferroelectrics often contain lead and other elements that raise environmental and processing concerns, prompting interest in lead-free analogues that preserve the same nanoscale polar behavior. Device designers will also need to balance the electric fields required for strong switching against dielectric breakdown limits, long-term reliability, and compatibility with existing semiconductor fabrication processes.
Another open question is how the effect behaves under realistic operating conditions, including repeated cycling, temperature swings, and mechanical stress. While the neutron-scattering experiments at the Spallation Neutron Source provide a detailed picture of phonon lifetimes and their field dependence, translating those insights into engineering models for complex devices will require further work.
Outlook: Designing Heat on Demand
Despite these hurdles, the demonstration of a nearly threefold, reversible change in thermal conductivity in a bulk solid marks a milestone for thermal science. It shows that heat flow, long treated as a passive byproduct of electronic operation, can be actively sculpted with external fields in much the same way that currents are steered by voltages. As researchers refine relaxor compositions, explore lead-free alternatives, and integrate these ceramics with other functional materials, the prospect of on-demand thermal pathways moves from theoretical curiosity toward practical technology.
In the longer term, the same principles could inform the design of materials where electrical, thermal, and even mechanical properties are all co-tuned through a single control knob. For now, the Oak Ridge work offers a clear proof-of-concept: by harnessing the complex polar landscape of relaxor ferroelectrics, it is possible to build a solid-state thermal switch that operates not at the margins, but with a level of contrast large enough to matter in real devices.
