Researchers at Saarland University in Germany have 3D-printed an electric motor rotor from metallic glass, a material that stays in an amorphous, glass-like atomic state instead of forming the crystalline grain structure found in conventional steel. The rotor, built from an iron-silicon-chromium-boron-carbon alloy, achieved record dimensions while keeping its disordered atomic arrangement largely intact. That structure matters because it sharply reduces the energy that motors waste as heat during operation, a problem that worsens as engineers push for smaller and faster designs in electric vehicles, drones, and household appliances.
Why Motor Cores Bleed Energy as Heat
Every electric motor contains a core that must reverse its magnetic polarity thousands of times per second. Each reversal generates what engineers call “iron loss,” a combination of hysteresis loss (friction at the atomic level as magnetic domains flip) and eddy current loss (small circulating currents induced in the metal). Both types convert useful electrical energy into waste heat. According to a Saarland press summary, the problem intensifies as motors shrink and spin faster, because higher operating frequencies multiply re-magnetization cycles and the heat they produce.
Conventional motor cores use silicon steel laminations to limit eddy currents, but the crystalline grain boundaries in those steels still allow significant hysteresis loss. Metallic glasses sidestep both problems. Their lack of long-range atomic order means magnetic domains can realign with far less resistance, and their high electrical resistivity suppresses eddy currents. The catch has always been manufacturing: metallic glasses are brittle and difficult to shape into the complex geometries that motor rotors demand, especially when designers want intricate cooling channels or integrated structural features.
3D Printing Solves the Shape Problem
The Saarland University team attacked that manufacturing barrier with laser powder bed fusion, a form of 3D printing that melts thin layers of metal powder with a focused laser beam. A peer-reviewed study in Materials & Design described how the group built a complex-shaped amorphous rotor from an Fe-Si-Cr-B-C-based bulk metallic glass-forming composition. The rotor achieved record dimensions for an additively manufactured amorphous component and remained largely amorphous, preserving the soft-magnetic properties that make metallic glass attractive for motor cores.
Keeping the material amorphous during printing is the central technical challenge. The laser must melt each powder layer hot enough to fuse it, yet cool it fast enough to prevent atoms from arranging into crystals. If crystallization creeps in, the magnetic advantages disappear. The team’s success depended on precise control of laser power, scan speed, hatch spacing, and layer thickness, parameters that together determine how much heat accumulates in the build and how rapidly each molten pool solidifies.
Because laser powder bed fusion builds parts layer by layer, the thermal history of any given region is complex: it may be remelted or reheated multiple times as neighboring tracks are scanned. That makes it easy for temperatures to linger in the range where crystals nucleate and grow. The Saarland researchers had to identify a narrow processing window where the alloy fully melts, densifies, and then vitrifies into a glassy state before crystals can form. Their rotor results show that this window exists at practical build speeds, at least for the specific alloy they used.
Fine-Tuning the Laser to Preserve Glass Structure
To generalize those findings, the team and collaborators ran more controlled experiments on a commercial Fe-based bulk metallic glass known as Kuamet 6B2. A study in Materialia examined how specific laser powder bed fusion settings affect microstructure, crystallinity, defects, porosity, and soft-magnetic behavior in this alloy. By systematically mapping process parameters to outcomes, the researchers identified which combinations kept the alloy amorphous and which tipped it toward unwanted crystallization.
The Materialia work also tracked how porosity—tiny voids left by incomplete melting or unstable melt pools—affected both mechanical strength and magnetic performance. High porosity can weaken a rotor structurally and disturb the magnetic flux paths that determine efficiency. The study found that parameter sets that minimized crystallization did not automatically minimize porosity, underscoring that engineers must balance densification, glass formation, and surface quality rather than optimizing any single metric in isolation.
Magnetic measurements from the Kuamet 6B2 samples reinforced this trade-off. Regions with higher crystallinity showed increased coercive field and higher core losses, eroding the benefits of using a metallic glass in the first place. Nearly fully amorphous regions, in contrast, exhibited low coercivity and soft-magnetic behavior closer to the theoretical potential of the alloy, but only when porosity and defects were also kept under control.
Cooling by Design: Switch-Off Time Delays
A third peer-reviewed paper in Additive Manufacturing introduced a more targeted tactic for managing heat: deliberately pausing the laser between scan vectors using so-called switch-off time delays. These brief pauses let accumulated heat dissipate before the next pass, reducing the risk of crystallization in previously solidified layers. Instead of relying solely on lower power or faster scan speeds, the researchers used timing to modulate the thermal cycle.
The Additive Manufacturing study measured the effects of varying delay lengths on density, defect formation, crystallinity, and coercive field, a key indicator of how easily the material can be magnetized and demagnetized. Longer delays generally promoted lower crystallinity and softer magnetic behavior, but excessively long pauses could hurt productivity and introduce other thermal gradients. The work highlights that time is as important a parameter as power or speed when the goal is to preserve an amorphous structure in a relatively thick, bulk part.
For motor designers, these process insights translate into a growing toolbox: by tuning laser power, scan strategy, and timing, it becomes possible to print not only simple test coupons but also complex three-dimensional geometries while keeping most of the volume amorphous. The Saarland rotor is an early demonstration of how those principles can be applied to a real component shape rather than a flat slab.
What the Research Shows (and What It Doesn’t)
Public-facing summaries of this work often frame it as a finished product ready for factory floors. That overstates the current state of the research. The published studies demonstrate a proof of concept: a rotor with record dimensions and promising magnetic properties, not a complete motor tested under real operating loads. No peer-reviewed data in the available literature provides side-by-side wattage or efficiency comparisons between an assembled metallic-glass motor and a conventional silicon-steel equivalent.
The distinction matters because scaling from a laboratory rotor to a production motor introduces new variables. Thermal management during continuous operation, mechanical fatigue over millions of cycles, vibration behavior at high speeds, and cost competitiveness with established lamination processes all remain open questions. Readers should treat the stated intent to 3D print fully amorphous motor components as a research goal rather than an accomplished engineering milestone.
There is also a risk of overlooking integration challenges. Metallic glasses can offer excellent magnetic properties but may behave differently under machining, balancing, or joining steps that are routine for crystalline steels. Any commercial motor would need not only a printable rotor but also compatible stator designs, insulation systems, and manufacturing workflows that preserve the amorphous state through all downstream processing.
The EU-Funded Program Behind the Research
All three studies emerged from the AM2SoftMag project, a European Union-funded initiative focused on additive manufacturing of amorphous metals for soft magnetic applications. The project’s results page, maintained by CORDIS, lists the peer-reviewed articles and conference proceedings that document the team’s progress, including work on process optimization, microstructural analysis, and component-level demonstrations such as the Saarland rotor.
The funding structure reflects a broader European policy push to support energy-efficiency technologies that could reduce electricity consumption across industrial and consumer sectors. Electric motors account for a substantial share of global power use, so even modest percentage improvements in core efficiency could translate into large absolute savings when deployed at scale. By backing early-stage work on amorphous metals and additive manufacturing, the EU is effectively betting that materials science and advanced processing can unlock those gains.
The AM2SoftMag outputs also include conference presentations and additional publications beyond the three core papers, suggesting the research group is building a systematic body of evidence rather than publishing isolated demonstrations. That breadth strengthens the scientific case, even as the engineering case for commercial production remains early-stage. At the same time, associated EU documentation underscores that official summaries may rely on machine translation and carry standard caveats about completeness and accuracy, another reason to read headline claims with care and defer to the peer-reviewed data where available.
What Comes Next
From here, the logical next steps are clear but nontrivial. Researchers will need to integrate these amorphous rotors into complete prototype motors, characterize their performance under realistic loads, and compare lifetime efficiency and reliability with incumbent designs. They will also need to explore whether similar process windows exist for other glass-forming alloys, including compositions tailored for higher temperatures or different frequency ranges.
If those hurdles can be cleared, 3D-printed metallic glass could give motor designers new freedom to sculpt magnetic circuits in three dimensions, embedding cooling channels, weight-saving cutouts, or unconventional topologies that are impossible with stacked laminations. For now, though, the Saarland work is best understood as a significant materials and manufacturing breakthrough—one that brings the promise of amorphous motor cores closer to reality, but still short of the plug-and-play revolution some coverage has implied.
