China has quietly pulled off a feat that solar engineers have chased for years, pushing a new cell design to record efficiency by hiding its most important features beneath the surface. Instead of simply layering materials on top of a silicon wafer, researchers have buried a critical interface inside the device, slashing defects and squeezing more electricity from every ray of light. The result is a lab-scale prototype that not only tops previous performance benchmarks but also hints at a new playbook for the next decade of photovoltaic manufacturing.
What makes this breakthrough stand out is not just the headline efficiency figure, but the way it rewrites assumptions about how far conventional materials can be pushed. By rethinking where the most fragile parts of the cell sit and how they are protected, the Chinese team has opened a path that could ripple from rooftop panels to utility-scale farms, especially as the country races toward terawatt-scale solar deployment.
How a buried interface pushed efficiency to the limit
The core innovation in China’s latest record cell is a buried interface that tackles one of solar engineering’s most stubborn problems, the tiny defects where electrons vanish before they can be harvested. Earlier approaches tried to coat the surface of perovskite and silicon layers with defect-fixing films, but those coatings were spread broadly and often introduced new weaknesses. In the new architecture, the team concentrated those corrective materials at a specific internal junction, a strategy that, according to reporting on the project, cut defects by about 90 percent and helped China’s solar cell reach its highest efficiency to date.
That buried interface matters because it sits where charge carriers are most likely to recombine, the process that turns potential current into wasted heat. Chinese researchers have described this recombination as the key challenge that had to be tamed, since every lost electron directly drags down the conversion rate. In detailed explanations of the device, they emphasized how the new structure channels electrons away from trap sites and into collection layers, a design that aligns with earlier accounts of Chinese researchers focusing on recombination as the bottleneck in high-end cells.
From 27.81% silicon to hybrid perovskites
This buried-interface milestone does not appear out of nowhere, it builds directly on a string of Chinese advances that have steadily raised the ceiling on what a single solar cell can do. Earlier in the current wave of innovation, a Chinese solar manufacturer pushed a silicon device to a verified efficiency of 27.81%, a figure that once seemed out of reach for this mature material system. That record silicon cell relied on intricate texturing, passivation, and contact engineering, proving that careful control of interfaces could still unlock meaningful gains even without exotic compounds.
Perovskite researchers have taken that lesson further by stacking materials and tailoring their boundaries, and the new buried design is a logical extension of that trend. A separate Chinese team reported record performance in perovskite devices that survived Results from Tests at 85 °C and 60% humidity, conditions that mimic harsh field environments and have historically shredded perovskite films. Those stability gains, combined with the buried-interface strategy, suggest that hybrid perovskite–silicon tandems are moving from fragile lab curiosities toward architectures that could survive on real rooftops and in desert arrays.
Peering inside with terahertz tools and buffer layers
One reason this new record was possible is that Chinese scientists have become adept at looking inside working cells without destroying them. A team led by a researcher named Chang turned to terahertz radiation to probe how charges move through next-generation devices, using a non-destructive detection technique to map bottlenecks that conventional electrical tests could only guess at. By scanning operating cells with this method, the group was able to identify where carriers slowed or vanished, then redesign those regions to improve transport, a process described in detail in coverage of researchers led by using terahertz tools to break efficiency bottlenecks.
At the same time, other Chinese groups have been rethinking the supporting layers that sit around the active materials, especially in flexible formats where mechanical stress can quickly create new defects. In one recent example, a team introduced a dual-layer buffer with a “loose-tight” structure that cushions bending while still maintaining strong electrical contact. That architecture, which was highlighted in reporting on Chinese researchers working on flexible solar cells, shows how mechanical and electronic engineering are converging, and it dovetails neatly with the buried-interface concept that also relies on carefully tuned intermediate layers.
From lab breakthrough to gigawatt reality
For all the excitement around record numbers, the real test is whether these designs can survive the brutal economics and scale of modern solar manufacturing. China is already on track for a Solar Boom, with national photovoltaic capacity projected to Capacity Set To roughly 1 TW, more than doubling the 87 GW installed in 2022. In that context, even a one or two percentage point gain in module efficiency can translate into enormous land, steel, and grid savings, which is why manufacturers are watching buried-interface and tandem designs so closely.
There are signs that Chinese institutions are already thinking in industrial terms rather than just laboratory heroics. The Qingdao Institute of Bioenergy and Bioprocess Technology, identified as QIB, has previously demonstrated how to translate complex processes into scalable membrane technologies, and that same mindset is now visible in solar, where researchers talk explicitly about reducing waste and cutting industrial costs. A separate analysis of record perovskite cells stressed that the new methods not only improved performance but also simplified fabrication steps, a combination that will be essential if buried interfaces are to move from a few square centimeters in a lab to gigawatt-scale production lines.
Why this buried design matters for the future of perovskites
Perovskite technology has long been haunted by a paradox: spectacular efficiencies in the lab paired with poor durability in the field. A major study published in Science and highlighted by a Hong Kong research institution described a “pivotal” advance that tackled one of the main barriers to deployment, namely the instability of perovskite layers under real-world operating conditions. That work was framed as a breakthrough because it addressed a major obstacle that had previously impeded wider adoption of perovskite solar cells, a point underscored in the institution’s description of a pivotal breakthrough for adapting these devices to renewable energy.
The buried-interface record from China fits squarely into that narrative, because it shows that stability and efficiency can be pursued together rather than traded off. By protecting the most sensitive junctions inside the device and pairing that structure with robust buffer layers and terahertz-guided diagnostics, engineers are starting to design perovskite and tandem cells that look less like fragile lab samples and more like the industrial workhorses that silicon has become. Industry-focused commentary on Solar Cell Efficiency has already framed Chinese advances as a signal for where the renewable industry is heading, and the buried design only sharpens that message: the next generation of solar will be won not just by new materials, but by how cleverly their hidden interfaces are engineered.
